Description
Digitally encoded 900 MHz spread
spectrum
operation
Robust, redundant communications
protocol
ensures high reliability
2 independent remote control channels
with 12
amp FET outputs
Minimum 2 mile line of sight in air
operation with
300mw transmitter power
RF groundplane on PC with high
reliability surface
mount construction
Interface daughter board isolates user
connections from the RF assembly
Ideally suited for redundant recovery
system
backup or remote aerial staging applications
16 bit exclusive transmitter ID allows
independent
operation / no impounding R/C units
No FCC licensing required / Part 15
compliant
Push button shroud on transmitter
prevents
accidental triggering
Single pushbutton operation – no ON/OFF
or
toggle switch combinations required
Audible ejection charge continuity
check with 10
µa sample current
Dual antenna system integral to
receiver board /
no external antenna required
Compression terminal strips for
battery, external
switch, and ejection charge wiring
DL-123A 3V lithium battery included for
transmitter rated for 1-2 years continuous operation
11-14 Vdc external battery required
with 40 ma
quiescent @ 12Vdc
Receiver board dimensions – 3.25″
height x 5.5″
long
Receiver weighs only 2.8 oz.
